Inconel 625 Welding Wire, 1100-1650MPa Tensile Strength & High Temperature Resistance

Place of Origin China
Brand Name KAIXIN
Certification ISO9001:2015
Model Number KX-Alloy IN625
Minimum Order Quantity 30kg
Price 38-40 USD/kg
Packaging Details Wooden Box, size as per guests request
Delivery Time 15-20 DAYS
Payment Terms T/T
Supply Ability 10000KG/MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

 Inconel 625  WELDING WIRE MIG



Product Description and Application



Inconel 625 is also known as the UNS N06625, SNi6625,Nr.2.4856, NC22DNb







Inconel 625 welding wire is a popular choice for welding Inconel 625 to itself, as well as to other materials such as steel and titanium. It is a type of high-strength alloy that is used in a variety of industrial applications, including chemical processing, power generation, and aerospace. Inconel 625 welding wire is characterized by its high corrosion resistance, high temperature resistance, and high strength. It is often used in environments where traditional materials such as carbon steel may be prone to corrosion or damage due to exposure to chemicals or high temperatures. To achieve the best results, it is important to use the correct type of welding wire and to follow proper welding techniques.





Process Performance and Requirements



  • Product Fusion Process



Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)



  • Product Chemical Composition



Alloy % Ni Cr Mo Nb Fe Al Ti C Mn Si Co P S
Inconel 625 Min Rem 20 8 3.15
Max   23 10 4.15 5 0.4 0.4 0.1 0.5 0.5 1 0.015 0.015



  • Product Physical Property



Density 8.44kg/m3
Melting point 1290-1350℃
Magnetic Property Nil



  • Product Mechanical Property



Density
8.44kg/m3
Melting point
1290-1350℃
Magnetic Property
Nil
Package
Welding Wire diameter
Allowable Deviation
vertical bar
1.6,1..8,2.0,2.4,2.5,2.8,3.0,3.2,
4.0,4.8,5.0,6.0,6.4
±0.1
Welding wire coil
+0.01
-0.04
Wire Reel
Diameter 100mm and 200mm
0.8,0.9,1.0,1.2,1.4,1.6
Wire Reel
Diameter 270mm and 300mm
0.5,0.8,0.9,1.0,1.2,1.4,1.6,2.0,
2.4,2.5,2.8,3.0,3.2
Welding wire can be produced in other sizes, deviations and package as agreed by both parties
Allowable deviation of ±0.1 diameter when used for hand-filled wire





  • Product Heat Treatment Institution



Rod and forgings, (1090~1200)℃x(1.5~2)h/WQ;

Wire, (1090-1200) ℃/≥ air cooling rate,

d≤3mm, insulation (9~15)min;

d3mm~5mm, insulation (15~20)min;

Hot rolled sheet, (950~1030)℃/AC,HB≤305hV;

Pipe, (960~1030)℃/AC or WQ





  • Professional Customization



Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm



Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm
