Product Details
Place of Origin: China
Brand Name: KAIXIN
Certification: ISO9001:2015
Model Number: KX-Alloy
Payment & Shipping Terms
Minimum Order Quantity: 200KG
Price: To negotiate
Packaging Details: Wooden Box, size as per guests request
Delivery Time: 45~60days
Payment Terms: T/T, L/C
Supply Ability: 50~80TONS per MONTH
Features: |
High Temperature Resistance, Corrosion Resistance And Oxidation Resistance |
Shape: |
Wire, Strip, Rod, Tube, Plate |
Alloy Type: |
Nickel-chromium-iron Based Alloy |
Raw Materials: |
NI≥72%,CR14-17% |
Executive Standard: |
ASTM |
Delivery State: |
Sosoloid |
Application: |
Thermocouple Pipe In Corrosive Atmosphere |
Size: |
Negotiable |
Features: |
High Temperature Resistance, Corrosion Resistance And Oxidation Resistance |
Shape: |
Wire, Strip, Rod, Tube, Plate |
Alloy Type: |
Nickel-chromium-iron Based Alloy |
Raw Materials: |
NI≥72%,CR14-17% |
Executive Standard: |
ASTM |
Delivery State: |
Sosoloid |
Application: |
Thermocouple Pipe In Corrosive Atmosphere |
Size: |
Negotiable |
KX W.Nr.2.4816 Light Rod Plate Structural Operating Temperature Range For High Temperature Alloy
Product Description and Application
W.Nr.2.4816 is also known as UNS N06600
W.Nr.2.4816 has good corrosion resistance to reducing, oxidizing and nitridating medium, good stress corrosion cracking resistance at room temperature and high temperature, good corrosion resistance to dry chlorine and hydrogen chloride gas, high strength below 650°C, good forming, easy welding. The maximum operating temperature reaches 1175°C in the air.
Process Performance and Requirements
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
| Ni | Cr | Fe | Cu | Mn | C | Si | S |
| ≥72.0 | 14.0～17.0 | 6.0～10.0 | ≤ 0.5 | ≤ 1.0 | ≤ 0.15 | ≤ 0.5 | ≤ 0.015 |
| Density | 8.4g/cm3 |
| Melting Point | 1370-1425°C |
| Yield Strength(MPa) | Tensile strength(MPa) | Elongation rate(%) | Hardness HB |
| ≥240 | ≥550 | ≥30 | ≤195 |
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe |
¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
