Product Details
Place of Origin: China
Brand Name: KAIXIN
Certification: ISO9001:2015
Model Number: KX-Alloy Cr-3
Payment & Shipping Terms
Minimum Order Quantity: 200KG
Price: To negotiate
Packaging Details: Wooden Box, size as per guests request
Delivery Time: 45~60days
Payment Terms: T/T, L/C
Supply Ability: 50~80TONS PER MONTH
Features: |
Good Corrosion Resistance, Oxidation Resistance, High Creep Strength, Stable Arc, Beautiful Forming And Good Flow Of Molten Iron, Which Includes Excellent Welding Performance. |
Alloy Type: |
Nickel-based Alloy |
Delivery State: |
Sosoloid |
Size: |
Negotiable |
Shape: |
Parcel Wire, Barrel Wire, Vertical Strip |
Raw Materials: |
NI≥67%,CR18-22%,Nb+Ta2.0-3.0% |
Executive Standard: |
GB/T15620-2008, AWS A5.14:2005 |
Application: |
Nickel-chromium Alloys (such As UNSNo6075, No7080), Nickel-chromium-iron Alloys (such As UNS No6600, No6601) And Nickel-chromium Alloys (such As UNSNo8800, No8801) Can Also Be Used For Welding.It Can Also Be Used For Welding Of Dissimilar Metal Joints And |
Features: |
Good Corrosion Resistance, Oxidation Resistance, High Creep Strength, Stable Arc, Beautiful Forming And Good Flow Of Molten Iron, Which Includes Excellent Welding Performance. |
Alloy Type: |
Nickel-based Alloy |
Delivery State: |
Sosoloid |
Size: |
Negotiable |
Shape: |
Parcel Wire, Barrel Wire, Vertical Strip |
Raw Materials: |
NI≥67%,CR18-22%,Nb+Ta2.0-3.0% |
Executive Standard: |
GB/T15620-2008, AWS A5.14:2005 |
Application: |
Nickel-chromium Alloys (such As UNSNo6075, No7080), Nickel-chromium-iron Alloys (such As UNS No6600, No6601) And Nickel-chromium Alloys (such As UNSNo8800, No8801) Can Also Be Used For Welding.It Can Also Be Used For Welding Of Dissimilar Metal Joints And |
KX NO6082 Welding Wire Light Rod on Nickel Based Welding Wire Alloy
Product Description and Application
NO6082 is also known as NO2061, NiTi3,SNi2061
NO6082 is used primarily in tungsten gas welding, molten gas welding and submerged arc welding in Nickel 200 and 201 alloys. It is also available in steel surfacing. The titanium and carbon in the weld metal react to reduce the free carbon to a relatively low level, so this electrode can be used for welding Nickel 201. Weld metal has excellent corrosion resistance, especially resistance to alkali metal corrosion. ERNi-1 wires can be used in a variety of welding situations, including Nickel 200, 201 alloys welding with stainless steel, carbon steel, INCONEL, INCOLOY, copper-nickel and MONEL alloys. It can also be used for welding between MONEL and copper-nickel alloys with carbon steel, copper-nickel alloys with INCONEL or INCOLOY alloys.
Process Performance and Requirements
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
| Welding Wire Model | Chemical Composition Code | C | Mn | Fe | Si | Cu | Nia | Coa | Al | Ti | Cr | Nbb |
| NO6082 | NiCr20Mn3Nb |
≤ 0.1 |
2.5 - 3.5 |
≤ 3.0 |
≤ 0.5 |
≤ 0.5 |
≤ 67.0 |
-- | -- | ≧0.7 |
18.0 - 22.0 |
2.0 - 3.0 |
| Density | 8.9g/cm3 |
| Melting Point | 1325-1370℃ |
Other Technical Requirements
Welding Wire Diameter and Allowable Deviation
| Package | Welding Wire Diameter | Allowable Deviation |
| Vertical Bar |
1.6,1..8,2.0,2.4,2.5,2.8,3.0,3.2, 4.0,4.8,5.0,6.0,6.4 |
±0.1 |
| Welding Wire Coil |
+0.01 -0.04 |
|
|
Wire Reel Diameter 100mm and 200mm |
0.8,0.9,1.0,1.2,1.4,1.6 | |
|
Wire Reel Diameter 270mm and 300mm |
0.5,0.8,0.9,1.0,1.2,1.4,1.6,2.0, 2.4,2.5,2.8,3.0,3.2 |
|
| Welding wire can be produced in other sizes, deviations and package as agreed by both parties | ||
|
Allowable deviation of ±0.1 diameter when used for hand-filled wire |
||
Welding Wire Loose Diameter and Warp Pitch
| Diameter of Wire Reel | 100 | 200 | 270,300 |
| Loose Diameter | 60~380 | 250~890 | 380~1300 |
| Warp Pitch | ≤13 | ≤19 | ≤25 |
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe |
¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
