Product Details
Place of Origin: China
Brand Name: KAIXIN
Certification: ISO9001:2015
Model Number: KX-AlloyC4
Payment & Shipping Terms
Minimum Order Quantity: 200KG
Price: To negotiate
Packaging Details: Wooden Box, size as per guest request
Delivery Time: 45~60days
Payment Terms: T/T, L/C
Supply Ability: 50~80TONS PER MONTH
Features: |
Corrosion Resistance |
Alloy Type: |
Nickel-molybdenum-chromium Alloy |
Size: |
Negotiable |
Shape: |
Wire, Strip, Rod, Pipe, Plate |
Delivery State: |
Sosoloid |
Raw Materials: |
Ni Rem%,Cr14.5-17.5%,Mo14-17% |
Executive Standard: |
ASTM |
Application: |
Wet Chlorine, Hypochlorous Acid, Hydrochloric Acid, Chloride Device |
Features: |
Corrosion Resistance |
Alloy Type: |
Nickel-molybdenum-chromium Alloy |
Size: |
Negotiable |
Shape: |
Wire, Strip, Rod, Pipe, Plate |
Delivery State: |
Sosoloid |
Raw Materials: |
Ni Rem%,Cr14.5-17.5%,Mo14-17% |
Executive Standard: |
ASTM |
Application: |
Wet Chlorine, Hypochlorous Acid, Hydrochloric Acid, Chloride Device |
KX NS335 Welding Wire Sheet Pipe Tubing Plate on Hastelloy Alloy
Product Description and Application
NS335 is also known as NS335 (China),.2.4610, NiMo16Cr16Ti(Germany), hastelloyc-4, UNS N06455(USA), NiMo16Cr16Ti(ISO)
NS335 has excellent corrosion resistance to most corrosive medium, especially in the reduced state. Excellent resistance to local corrosion in halides has been widely used in most chemical industry and high temperature environment. Typical application areas are flue gas desulfurization system, pickling and acid recycling plants, acetic acid and agricultural chemicals production, titanium dioxide production (chlorine process), electrolytic plating.
Process Performance and Requirements
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
| Ni | Cr | Fe | C | Mn | Si | Mo | Co | Ti | P | S | |
| Min | Rem | 14.5 | 14.0 | 0.01 | |||||||
| Max | 17.5 | 3.0 | 0.009 | 1.0 | 0.05 | 17.0 | 2.0 | 0.7 | 0.02 |
| Density | 8.64g/cm3 |
| Melting point | 1399℃ |
| Magnetic Property | Nil |
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe |
¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
