Product Details
Place of Origin: China
Brand Name: KAIXIN
Certification: ISO9001:2015
Model Number: KX-Alloy Mo-3
Payment & Shipping Terms
Minimum Order Quantity: 200KG
Price: To negotiate
Packaging Details: Wooden Box, size as per guests request
Delivery Time: 45~60days
Payment Terms: T/T, L/C
Supply Ability: 50~80TONS PER MONTH
Features: |
Good Corrosion Resistance, Oxidation Resistance, High Creep Strength, Stable Arc, Beautiful Forming, Good Flow Of Molten Iron, Excellent Welding Technological Properties |
Alloy Type: |
Nickel-based Alloy |
Delivery State: |
Sosoloid |
Size: |
Negotiable |
Shape: |
Parcel Wire, Coiling Wire, Vertical Bar |
Raw Materials: |
NI≤58%,CR20-23%,Nb+Ta3.15-4.15% |
Executive Standard: |
GB/T15620 SNi6082 AWS A5.14 ERNiCr-3 EN ISO18274:S Ni 6082 |
Application: |
Petrochemical Industry |
Features: |
Good Corrosion Resistance, Oxidation Resistance, High Creep Strength, Stable Arc, Beautiful Forming, Good Flow Of Molten Iron, Excellent Welding Technological Properties |
Alloy Type: |
Nickel-based Alloy |
Delivery State: |
Sosoloid |
Size: |
Negotiable |
Shape: |
Parcel Wire, Coiling Wire, Vertical Bar |
Raw Materials: |
NI≤58%,CR20-23%,Nb+Ta3.15-4.15% |
Executive Standard: |
GB/T15620 SNi6082 AWS A5.14 ERNiCr-3 EN ISO18274:S Ni 6082 |
Application: |
Petrochemical Industry |
KX NO6625 Welding Wire Light Rod on Nickel Based Welding Wire Alloy
Product Description and Application
NO6625 is also known as the SNI6625, NiCr22Mo9Nb
NO6625 is a corrosion-resistant nickel - based welding wire. It is used for petroleum pipeline, valve surfacing, waste incineration and etc. Weld metal has good impact strength and high brittleness resistance, which is suitable for welding of dissimilar steel and its working temperature is 450-550 °C. It is also suitable for high temperature and even high humidity corrosive environment exposure. NO6625 and nickel-based composite welding alloys are supplied with welding rod and wires in standard length or as required by customers.
Process Performance and Requirements
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
| C | Mn | Fe | P | S | Si | Cu | Ni | Al | Ti | Cr | Nb+Ta | Mo | Other |
| 0.1 | 0.5 | 5.0 | 0.02 | 0.015 | 0.5 | 58 | 0.4 | 0.4 | 0.4 | 20.0-23.0 | 3.15-4.15 | 8.0-10.0 | 0.5 |
| Density | 8.44kg/m3 |
| Melting point | 1290-1350℃ |
| Magnetic Property | Nil |
Welding Wire Diameter and Allowable Deviation
| Package | Welding Wire diameter | Allowable Deviation |
| vertical bar |
1.6,1..8,2.0,2.4,2.5,2.8,3.0,3.2, 4.0,4.8,5.0,6.0,6.4 |
±0.1 |
| Welding wire coil |
+0.01 -0.04 |
|
|
Wire Reel Diameter 100mm and 200mm |
0.8,0.9,1.0,1.2,1.4,1.6 | |
|
Wire Reel Diameter 270mm and 300mm |
0.5,0.8,0.9,1.0,1.2,1.4,1.6,2.0, 2.4,2.5,2.8,3.0,3.2 |
|
| Welding wire can be produced in other sizes, deviations and package as agreed by both parties | ||
| Allowable deviation of ±0.1 diameter when used for hand-filled wire | ||
Welding Wire Loose Diameter and Warp Pitch
| Diameter of Wire Reel | 100 | 200 | 270,300 |
| Loose Diameter | 60~380 | 250~890 | 380~1300 |
| Warp Pitch | ≤13 | ≤19 | ≤25 |
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe |
¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
